Contec ND63 10.1" Rugged Tablet
Contec ND63 10.1" Rugged Tablet

Contec ND63 10.1" Rugged Tablet

ND63 | 10.1" Rugged Industrial Tablet | MIL-STD-810G | IP65 | Contec Americas Contact Sales Department for Pricing MIL-STD-810G IP65 5ft Drop-Proof Hot-Swap Battery 800 Nits Sunlight Readable Intel Alder Lake-N Wi-Fi 6E · BT 5.3 Win 10 IoT / Win 11 MIL-STD-810G tested and IP65 sealed, the ND63 is...
Vendor: Contec Americas Inc.
SKU: Contec ND63 10.1"
Availability: In Stock
Product type: Industrial Display
$0.00 USD
$0.00 USD
Subtotal: $0.00 USD
📋

Datasheet

Contec ND63 10.1" Rugged Tablet

Download PDF

Free Shipping

Free standard shipping on orders over $500

Secure Payments

PCI DSS compliant processing

Prices are subject to change based on applicable tariffs.

Prices are subject to change based on applicable tariffs and import duties. We will notify customers of any price changes before order confirmation.
Description
ND63 | 10.1" Rugged Industrial Tablet | MIL-STD-810G | IP65 | Contec Americas
MIL-STD-810G IP65 5ft Drop-Proof Hot-Swap Battery 800 Nits Sunlight Readable Intel Alder Lake-N Wi-Fi 6E · BT 5.3 Win 10 IoT / Win 11

MIL-STD-810G tested and IP65 sealed, the ND63 is a 10.1" rugged industrial tablet built for field, vehicle, and facility deployments. Intel Alder Lake-N processing, a 1920×1200 IPS display at 800 nits, Wi-Fi 6E, hot-swap battery, and an extensive optional accessory ecosystem make it a complete mobile platform for demanding industrial environments.

MIL STD-810G Certified
IP65 Dust-Tight · Water Jet Resistant
800 Nits — Sunlight Readable
7hr Battery Life — Hot-Swap
Contec Americas
Rugged Industrial Tablets
MIL-STD-810G · IP65 · Intel Alder Lake-N · Wi-Fi 6E · Hot-Swap Battery
View Collection

Built for the Field,
the Vehicle, and the Facility

The ND63 is engineered for industrial deployments where consumer tablets fail — multiple 5ft / 1.5m drops per MIL-STD-810G, IP65 sealing against dust and water jets, and a 1-meter tumble test. A hot-swappable 4170mAh battery keeps the device operational through shift changes without powering down, backed by an internal 142mAh backup battery that maintains system state during the swap.

Durability Certifications
  • MIL-STD-810G — multiple 5ft / 1.5m drop tests
  • IP65 — fully dust-tight, water jet resistant
  • 1-meter tumble test
  • Steel ball drop test — 25mm, 250g from 50cm
  • Operating temp: -10°C to 50°C
Power and Mobility
  • Hot-swap battery — no shutdown required
  • 7.68V / 4170mAh / 32Wh — up to 7 hours
  • Backup battery: 7.4V / 142mAh — maintains state during swap
  • AC adapter 65W (19V / 3.42A)
  • Optional USB-C PD 65W adapter

The hot-swap battery architecture means the ND63 never needs to be powered down for a battery change during a shift — critical for warehouse, logistics, and field service applications where device downtime directly affects workflow throughput.

Display, Processing,
and Connectivity

The 10.1" IPS display runs at 1920×1200 (16:10) with 800 nits brightness — sunlight readable in outdoor field and yard environments. Intel Alder Lake-N N100/N200 processing and 16GB LPDDR5 RAM deliver the performance headroom needed for industrial applications, data collection, and real-time workflows.

Processing and Display
  • Intel Alder Lake-N N100 / N200 (optional N50)
  • 16GB LPDDR5 on-board (optional 8GB)
  • 256GB SSD (optional 512GB or 1TB)
  • 10.1" IPS 1920×1200 — 800 nits, sunlight readable
  • 10-point multi-touch — glove mode and wet-touch mode
Wireless and Connectivity
  • Wi-Fi 6E (802.11ax) — latest wireless standard
  • Bluetooth 5.3
  • GPS / GLONASS / GALILEO
  • Optional 4G LTE — Quectel EM060-K (EMEA)
  • RJ45 Gigabit Ethernet with PXE support

Interface and
Security

  • USB 3.1 Type-A × 1 + USB 3.1 Type-C × 1 — high-speed peripheral and data transfer.
  • HDMI Micro connector — external display output for presentations and workstation setups.
  • RJ45 Gigabit Ethernet with PXE — wired network access and remote provisioning support.
  • Nano SIM + Micro SDXC card readers — cellular connectivity and expandable storage.
  • Docking connector — compatible with optional vehicle dock and office dock for deployments requiring a fixed charging and I/O station.
  • Firmware TPM 2.0 — hardware-rooted security for enterprise deployments. Optional Hardware TPM also available.
  • Kensington cable lock slot — physical security in shared or semi-attended installations.
  • Optional Windows Hello camera — biometric authentication for secure, hands-free login.

Full Specifications

Category Specification
Operating System Windows 10 IoT Enterprise, Windows 11
CPU Intel Alder Lake-N N100 / N200 (optional N50)
Memory 16GB LPDDR5 on-board (optional 8GB)
Storage 256GB SSD (optional 512GB or 1TB)
Display 10.1" IPS, 16:10, 1920×1200, 800 nits, sunlight readable
Touch 10-point multi-touch — glove mode and wet-touch mode, MPP 2.0 support
Audio 2 × 2W speaker, 2 × digital microphone, 3.5mm audio jack
Cameras 2MP front (optional Windows Hello), 8MP rear with autofocus and flash
Wireless Wi-Fi 6E (802.11ax), Bluetooth 5.3, GPS / GLONASS / GALILEO
Optional Cellular 4G LTE — Quectel EM060-K (EMEA)
Interface USB 3.1 Type-A × 1, USB 3.1 Type-C × 1, RJ45 GbE (PXE), HDMI Micro, 3.5mm audio, Nano SIM, Micro SDXC, Docking connector, Reset hole, Replaceable DC jack
Security Firmware TPM 2.0, optional Hardware TPM, Kensington lock slot, optional Windows Hello
Battery 7.68V / 4170mAh / 32Wh — up to 7 hours, hot-swappable
Backup Battery 7.4V / 142mAh / 1.05Wh — maintains state during hot-swap
Power Supply AC adapter 65W (19V / 3.42A) — optional USB-C PD 65W (20V / 3.25A)
Sensors 9-axis MEMS (accelerometer, eCompass, gyroscope), ambient light, proximity
LED Indicators Power, battery, Wi-Fi
Physical Buttons Power, volume +/-, 2 × programmable function keys
Durability MIL-STD-810G (multiple 5ft / 1.5m drops), IP65, 1m tumble test, steel ball drop test
Operating Temperature -10°C to 50°C
Storage Temperature -20°C to 60°C
Dimensions 283 × 192 × 15mm (11.1" × 7.6" × 0.6")
Weight 990g (without screen protector)

Optional Accessories

Docking and Power
  • Vehicle dock — secure in-cab mounting and charging
  • Office dock — desk charging and I/O expansion
  • Battery charger — multi-bay for shift-change battery management
  • USB-C PD adapter 65W (20V / 3.25A)
Input and Data Capture
  • 1D / 2D Honeywell barcode reader
  • Capacitive stylus pen
  • Digitizer (MPP 2.0 compatible)
  • Briefcase handle and hand strap with stylus holder

Ready to deploy a rugged industrial tablet?

The ND63 is available through Contec Americas on a quote basis. Contact our sales team to discuss configuration, accessory selection, and deployment requirements for your application.

Tags Rugged Tablet Industrial Tablet MIL-STD-810G Tablet IP65 Tablet 10.1 Inch Rugged Tablet Windows Industrial Tablet Hot Swap Battery Tablet Intel Alder Lake Tablet Wi-Fi 6E Tablet Sunlight Readable Tablet Field Service Tablet Warehouse Tablet Vehicle Mount Tablet ND63 Contec Rugged Tablet TPM 2.0 Tablet
